When the switch or HUB is connected to the router, the computer is connected to the switch or HUB, and the switch is connected to the switch through the UPLINKS port, Category 6 network cables can be used for direct wiring
Super Category 6 network cable can be used in network connection, wiring engineering, termination between equipment or horizontal subsystem, and connection between equipment port and modular jumper system. For example, connect the LAN interface between the telecommunication broadband ADSL MODEM and the wireless router router, switch, hub, firewall and other equipment and the network card interface of the computer. Due to its dual shielding and high-speed performance, it is also suitable for high-speed network deployment of various large enterprises, as well as various complex electromagnetic environments or occasions requiring shielding
When the computer is connected to the router, the switch is connected to the switch, and the HUB is connected to the HUB; When two PCs are directly connected, the router interface is connected with other router interfaces, and the Ethernet interface ADSL Modem is connected to the network card interface of the PC, the super six network cables can be used for cross connection
It is worth noting that the transmission performance of the super Category 6 network cable is higher than that of the Category 6 network cable. The IEEE standard also clearly states that the super Category 6 network cable can support 10Gbps network connection. But in practical applications, when trying to use six types of network cables in 10G networks, is this feasible
In fact, some people have indeed proved that the transmission distance of Category 6 network cable can reach 37-55m at the transmission rate of 10Gbps when the external crosstalk is very small. But this is difficult to implement in practical applications. First of all, the deployment of network cables is usually dense, so external crosstalk cannot be very small; Secondly, like the super Class 6 network cable, the heat dissipation performance of the Class 6 network cable is not very good, and the network cable will inevitably heat up in the process of transmitting data, which will reduce the transmission rate of the network cable. In general, it is not recommended to use Category 6 network cable in 10GBASE-T network, but use Category 6 network cable
